530 PLUS
Socket:
LED
Beam Angle:
>90º
Complements:
Ice Diffuser
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days
530 PLUS
Fixed recessed spotlight made of die-casted zamak, designed for high performance LED with different diffuser options. Remote LED driver included and optional dimmable
1-10V, PUSH or DALI version available.
| W | mA | Temp. | Lum. | CRI | |
|---|---|---|---|---|---|
| 530 PLUS | 11W | 350 mA | 2.7K | 1.675 lm | 92 |
| 11W | 350 mA | 3K | 1.870 lm | 92 | |
| 11W | 350 mA | 4K | 1.940 lm | 92 | |
| 530 PLUS | 17W | 500 mA | 2.7K | 2.455 lm | 92 |
| 17W | 500 mA | 3K | 2.640 lm | 92 | |
| 17W | 500 mA | 4K | 2.730 lm | 92 | |
| 530 PLUS | 23W | 700 mA | 2.7K | 3.260 lm | 92 |
| 23W | 700 mA | 3K | 3.505 lm | 92 | |
| 23W | 700 mA | 4K | 3.625 lm | 92 |
To help customizing this product, we have created a simple step by step configurator. Click on the button to start.
Technical Datasheet
LDT File
