Gamma di proiettori con ottica di precisione. Controllo dell’abbagliamento per applicazioni in interno

  • presa
  • uscita
  • controllo
  • temperatura del colore
  • Beam Angle
  • Complementi
  • finitura

Questa combinazione non esiste.

Contattaci
Focus 40 R Focus 40 R
Technical Datasheet CE Declaration Technical Catalogue Installation Instructions General Guarantee Conditions Extended Guarantee Conditions LED Efficiency Label LED technical datasheet Driver technical datasheet Test report certificate Test report FOCUS 40 R - LDT files
Disegno tecnico
Flusso LED—
Consumo LED—
Efficienza luminosa—
CRI—
Driver LED—
Temperatura della luce—
Angolo di apertura—
Protezione IP—
Focus 40 R
Focus 40 R
Modelo Ref. Color Fuente Potencia Regulación Flujo lum. Temp. Ángulo CRI Eficiencia
Focus 40 R 2700K FCS4A40D22ABS Nero satinato LED Ø40 / ≈ 6W / >600 lm Dali 674 lm 2700K 25º >90 112 lm/W
Focus 40 R 2700K FCS4A40D22AWB Bianco - nero LED Ø40 / ≈ 6W / >600 lm Dali 674 lm 2700K 25º >90 112 lm/W
Focus 40 R 3000K FCS4A40D32ABS Nero satinato LED Ø40 / ≈ 6W / >600 lm Dali 705 lm 3000K 25º >90 118 lm/W
Focus 40 R 3000K FCS4A40D32AWB Bianco - nero LED Ø40 / ≈ 6W / >600 lm Dali 705 lm 3000K 25º >90 118 lm/W
Focus 40 R 4000K FCS4A40D42ABS Nero satinato LED Ø40 / ≈ 6W / >600 lm Dali 745 lm 4000K 25º >90 124 lm/W
Focus 40 R 4000K FCS4A40D42AWB Bianco - nero LED Ø40 / ≈ 6W / >600 lm Dali 745 lm 4000K 25º >90 124 lm/W
Focus 40 R 2700K FCS4A40K22ABS Nero satinato LED Ø40 / ≈ 6W / >600 lm Casambi — 2700K 24º — —
Focus 40 R 2700K FCS4A40K22AWB Bianco - nero LED Ø40 / ≈ 6W / >600 lm Casambi — 2700K 24º — —
Focus 40 R 3000K FCS4A40K32ABS Nero satinato LED Ø40 / ≈ 6W / >600 lm Casambi — 3000K 24º — —
Focus 40 R 3000K FCS4A40K32AWB Bianco - nero LED Ø40 / ≈ 6W / >600 lm Casambi — 3000K 24º — —
Focus 40 R 4000K FCS4A40K42ABS Nero satinato LED Ø40 / ≈ 6W / >600 lm Casambi — 4000K 24º — —
Focus 40 R 4000K FCS4A40K42AWB Bianco - nero LED Ø40 / ≈ 6W / >600 lm Casambi — 4000K 24º — —
Focus 40 R 2700K FCS4A40N22ABS Nero satinato LED Ø40 / ≈ 6W / >600 lm No Dimmable 694 lm 2700K 25º >90 89 lm/W
Focus 40 R 2700K FCS4A40N22AWB Bianco - nero LED Ø40 / ≈ 6W / >600 lm No Dimmable 694 lm 2700K 25º >90 89 lm/W
Focus 40 R 3000K FCS4A40N32ABS Nero satinato LED Ø40 / ≈ 6W / >600 lm No Dimmable 745 lm 3000K 25º >90 96 lm/W
Focus 40 R 3000K FCS4A40N32AWB Bianco - nero LED Ø40 / ≈ 6W / >600 lm No Dimmable 745 lm 3000K 25º >90 96 lm/W
Focus 40 R 4000K FCS4A40N42ABS Nero satinato LED Ø40 / ≈ 6W / >600 lm No Dimmable 796 lm 4000K 25º >90 102 lm/W
Focus 40 R 4000K FCS4A40N42AWB Bianco - nero LED Ø40 / ≈ 6W / >600 lm No Dimmable 796 lm 4000K 25º >90 102 lm/W
