DOT TILT

https://onoklighting.com/web/image/product.template/6304/image_1920?unique=affed53

High performance – comfortable and precise light

With a CRI > 90, this luminaire guarantees natural light and excellent visual comfort thanks to its anti-glare lens. The adjustable version is perfect for indirect lighting or as a wall washer.
​

  • Socket
  • Output
  • Control
  • Colour Temperature
  • Beam Angle
  • Complements
  • Finish

This combination does not exist.

Contact Us
Socket: LED
Beam Angle: 36º
Complements: Ice Diffuser
Finish: Satin Black
Modelo Ref. Color Fuente Potencia Regulación Flujo lum. Temp. Ángulo CRI Eficiencia
DOT TILT 2700K DOTTA05D23ABS Satin Black LED 5P / ≈ 10W / >1.000 lm Dali 1.000 lm 2700K 30º >90 100 lm/W
DOT TILT 3000K DOTTA05D33ABS Satin Black LED 5P / ≈ 10W / >1.000 lm Dali 1.097 lm 3000K 30º >90 110 lm/W
DOT TILT 4000K DOTTA05D43ABS Satin Black LED 5P / ≈ 10W / >1.000 lm Dali 1.155 lm 4000K 30º >90 115 lm/W
DOT TILT 2700K DOTTA05F23ABS Satin Black LED 5P / ≈ 10W / >1.000 lm PUSH 1.000 lm 2700K 30º >90 100 lm/W
DOT TILT 3000K DOTTA05F33ABS Satin Black LED 5P / ≈ 10W / >1.000 lm PUSH 1.097 lm 3000K 30º >90 110 lm/W
DOT TILT 4000K DOTTA05F43ABS Satin Black LED 5P / ≈ 10W / >1.000 lm PUSH 1.155 lm 4000K 30º >90 115 lm/W
DOT TILT 2700K DOTTA05N23ABS Satin Black LED 5P / ≈ 10W / >1.000 lm No Dimmable 1.000 lm 2700K 30º >90 100 lm/W
DOT TILT 3000K DOTTA05N33ABS Satin Black LED 5P / ≈ 10W / >1.000 lm No Dimmable 1.097 lm 3000K 30º >90 110 lm/W
DOT TILT 4000K DOTTA05N43ABS Satin Black LED 5P / ≈ 10W / >1.000 lm No Dimmable 1.155 lm 4000K 30º >90 115 lm/W
DOT TILT 2700K DOTTA10D23ABS Satin Black LED 10P / ≈ 21W / >2.000 lm Dali 2.100 lm 2700K 30º >90 105 lm/W
DOT TILT 3000K DOTTA10D33ABS Satin Black LED 10P / ≈ 21W / >2.000 lm Dali 2.158 lm 3000K 30º >90 108 lm/W
DOT TILT 4000K DOTTA10D43ABS Satin Black LED 10P / ≈ 21W / >2.000 lm Dali 2.310 lm 4000K 30º >90 116 lm/W
DOT TILT 2700K DOTTA10F23ABS Satin Black LED 10P / ≈ 21W / >2.000 lm PUSH 2.100 lm 2700K 30º >90 105 lm/W
DOT TILT 3000K DOTTA10F33ABS Satin Black LED 10P / ≈ 21W / >2.000 lm PUSH 2.158 lm 3000K 30º >90 108 lm/W
DOT TILT 4000K DOTTA10F43ABS Satin Black LED 10P / ≈ 21W / >2.000 lm PUSH 2.310 lm 4000K 30º >90 116 lm/W
DOT TILT 2700K DOTTA10N23ABS Satin Black LED 10P / ≈ 21W / >2.000 lm No Dimmable 2.100 lm 2700K 30º >90 105 lm/W
DOT TILT 3000K DOTTA10N33ABS Satin Black LED 10P / ≈ 21W / >2.000 lm No Dimmable 2.158 lm 3000K 30º >90 108 lm/W
DOT TILT 4000K DOTTA10N43ABS Satin Black LED 10P / ≈ 21W / >2.000 lm No Dimmable 2.310 lm 4000K 30º >90 116 lm/W
