Range of projectors with recessed design for glare control. Precise lighting with visual comfort.
  • Socket
  • Output
  • Control
  • Colour Temperature
  • Beam Angle
  • Complements
  • Finish

This combination does not exist.

Contact Us
Click Focus 25 Click Focus 25
Technical Datasheet Click Catalogue CE Declaration for Surface and Pendant CE Declaration for Recessed Bluetooth Catalogue Installation Instructions General Guarantee Conditions EXTENDED Guarantee Conditions LED Efficiency Label Driver technical datasheet LED technical datasheet Test report certificate (Recessed profile) Test report (Recessed profile) Test report certificate (Surface profile) Test report (Surface profile) CLICK FOCUS 25 - LDT files
Technical drawing
LED flux—
LED power consumption—
Luminous efficiency—
CRI—
Driver LED—
Light temperature—
Beam angle—
IP protection—
Modelo Ref. Color Fuente Potencia Regulación Flujo lum. Temp. Ángulo CRI Eficiencia
Click Focus 25 2700K KFC2A25D22ABS Satin Black LED Ø25 / ≈ 6W / >500 lm Dali 2x521 lm 2700K 25º >90 87 lm/W
Click Focus 25 2700K KFC2A25D22AWS Satin White LED Ø25 / ≈ 6W / >500 lm Dali 2x521 lm 2700K 25º >90 87 lm/W
Click Focus 25 3000K KFC2A25D32ABS Satin Black LED Ø25 / ≈ 6W / >500 lm Dali 2x559 lm 3000K 25º >90 93 lm/W
Click Focus 25 3000K KFC2A25D32AWS Satin White LED Ø25 / ≈ 6W / >500 lm Dali 2x559 lm 3000K 25º >90 93 lm/W
Click Focus 25 4000K KFC2A25D42ABS Satin Black LED Ø25 / ≈ 6W / >500 lm Dali 2x597 lm 4000K 25º >90 100 lm/W
Click Focus 25 4000K KFC2A25D42AWS Satin White LED Ø25 / ≈ 6W / >500 lm Dali 2x597 lm 4000K 25º >90 100 lm/W
Click Focus 25 2700K KFC2A25K22ABS Satin Black LED Ø25 / ≈ 6W / >500 lm Casambi 2x521 lm 2700K 25º >90 87 lm/W
Click Focus 25 2700K KFC2A25K22AWS Satin White LED Ø25 / ≈ 6W / >500 lm Casambi 2x521 lm 2700K 25º >90 87 lm/W
Click Focus 25 3000K KFC2A25K32ABS Satin Black LED Ø25 / ≈ 6W / >500 lm Casambi 2x559 lm 3000K 25º >90 93 lm/W
Click Focus 25 3000K KFC2A25K32AWS Satin White LED Ø25 / ≈ 6W / >500 lm Casambi 2x559 lm 3000K 25º >90 93 lm/W
Click Focus 25 4000K KFC2A25K42ABS Satin Black LED Ø25 / ≈ 6W / >500 lm Casambi 2x597 lm 4000K 25º >90 100 lm/W
Click Focus 25 4000K KFC2A25K42AWS Satin White LED Ø25 / ≈ 6W / >500 lm Casambi — 4000K 24º — —
Click Focus 25 2700K KFC2A25N22ABS Satin Black LED Ø25 / ≈ 6W / >500 lm No Dimmable 2x521 lm 2700K 25º >90 87 lm/W
Click Focus 25 2700K KFC2A25N22AWS Satin White LED Ø25 / ≈ 6W / >500 lm No Dimmable 2x521 lm 2700K 25º >90 87 lm/W
Click Focus 25 3000K KFC2A25N32ABS Satin Black LED Ø25 / ≈ 6W / >500 lm No Dimmable 2x559 lm 3000K 25º >90 93 lm/W
Click Focus 25 3000K KFC2A25N32AWS Satin White LED Ø25 / ≈ 6W / >500 lm No Dimmable 2x559 lm 3000K 25º >90 93 lm/W
Click Focus 25 4000K KFC2A25N42ABS Satin Black LED Ø25 / ≈ 6W / >500 lm No Dimmable 2x597 lm 4000K 25º >90 100 lm/W
Click Focus 25 4000K KFC2A25N42AWS Satin White LED Ø25 / ≈ 6W / >500 lm No Dimmable 2x597 lm 4000K 25º >90 100 lm/W
