KONO 1
Fixed recessed spotlight made of polycarbonate, designed for high performance LED with different diffuser options. Remote LED driver included and optional dimmable IGBT/ TRIAC, 1-10V or PUSH version available.
*White finished textured
Socket
GU10
,
LED
Output
≈ 6W / >600 lm
,
≈ 10W / >1000 lm
,
Max. 10W
Control
PUSH
,
Dali
,
Driver not included
,
No Dimmable
Colour Temperature
2700K
,
3000K
,
4000K
,
ºK not available
Beam Angle
40º
,
16º
,
Å not available (lamp not included)
,
24º
Complements
Clear Diffuser
,
Ice Diffuser
,
No Diffuser
Finish
| W | mA | Temp. | Lum. | CRI | |
|---|---|---|---|---|---|
| KONO 1 | 6W | 150 mA | 2.7K | 570 lm | 92 |
| 6W | 150 mA | 3K | 595 lm | 92 | |
| 6W | 150 mA | 4K | 635 lm | 92 | |
| KONO 1 | 10W | 300 mA | 2.7K | 1.005 lm | 92 |
| 10W | 300 mA | 3K | 1.070 lm | 92 | |
| 10W | 300 mA | 4K | 1.135 lm | 92 | |
| KONO 1 | Max. 10W | No Lamp | X | No lamp | No lamp |
To help customizing this product, we have created a simple step by step configurator. Click on the button to start.
-
Technical Datasheet
-
Installation Instructions
-
LED Efficiency Label
-
General Guarantee Conditions
-
2D - dwg
-
2D - dxf
-
3D - step
-
Extended Guarantee Conditions
-
CE Declaration for GU 10
-
CE Declaration for LED
-
Test report certificate
-
Driver Technical datasheet
-
LED 6W Technical datasheet
-
LED 10W Technical datasheet
LDT File
